Cartridge Filter Element SF50007 25 Micron Microglass

WE CARRY A LARGE INVENTORY OF JOHN CRANE INDUFIL FCN3163D FILTER ELEMENT REPLACEMENTS.
PLEASE CONTACT US FOR A QUOTE

Swift Filters SF50007 microglass cartridge filter element is a highly durable 25 micron hydraulic filter element.

It is an economical high performance true equivalent John Crane Indufil FCN3163D filter element replacement in fit, form and function.

The Swift Filters Microglass Indufil Replacement Filter Advantage
Our hydraulic filter elements are engineered to exceed OEM filtration requirements.

Made from SWIFTGLASS® microglass filter media featuring high strength dual-phase synthetic fibers bonded with a stable resin set into a pleated multilayer construction,

Our filters are known to be one of the most efficient and cost-effective hydraulic cartridge filter elements available in the market today.

SF50007 Cartridge Filter Element Specifications
•    MICRON RATING: 25  micron
•    MEDIA TYPE: SWIFTGLASS® high performance microglass
•    SEAL MATERIAL: Viton® (Fluorocarbon Type A)
•    COLLAPSE: Can withstand pressure up to 150 PSI

FILTER ELEMENT DIMENSIONS:
Inner Diameter   3.352 in.
Outer Diameter  5.130 in.
Overall Length  37.100 in.

ISO16889 multi-pass and Dynamic Filter Efficiency (DFE) testing
Efficiencies up to 99.9% (ß1>1000)

Ideal for Demanding Hydraulic Filtration Applications Including:
Hydraulic fluids
Lubrication oils (including synthetic)
Fuels including gasoline and diesel
Coolants and process fluids
Water glycols (HFAE, HFAS, HFB and HFC)
Seal gas filtration

WE CARRY A LARGE INVENTORY OF JOHN CRANE INDUFIL FCN3163D FILTER ELEMENT REPLACEMENTS.
PLEASE CONTACT US FOR A QUOTE

Made in the USA, Swift Filters specializes in the design and manufacture of high-quality replacement filter elements and custom filter elements for a wide variety of industries.
